3V1-06 Airtac Type Pneumatic Solenoid Valve 3 Way 2 Position 24VDC

Brand Name : Brando

Model Number : 3V1-06

Certification : CE

Place of Origin : China

MOQ : 1 pc

Price : Negotiation

Payment Terms : T/T, PayPal, Western Union

Supply Ability : 200000 pcs per month

Delivery Time : Negotiation

Packaging Details : Individual box, Carton, Pallet

Fluids : Air (to be filtered by 40 μ m filter element)

Action : Direct Acting

Function : 3 Way, Normally Closed (NC)

Orifice Size : 1.0mm

Port Size : 1/8''

Pressure Range : 0 to 0.8MPa

Max Pressure Resistance : 1.2MPa

Body Material : Aluminum Alloy

Max. Frequency : 10 Cycle / Second

Voltage : 12VDC, 24VDC, 110VAC, 220VAC

Contact Now

3V1-06 Airtac Type Pneumatic Solenoid Valve 3 Way 2 Position 24VDC

Product Features of 3V1 series solenoid valve:

1. Direct acting type and normally closed mode, flexible in direction change.
2. No need to add oil for lubrication.
3. Several valves can be installed integrately to save installation space.
4. Affiliated manual devices are equipped to facilitate installation and debugging.
5. Several standard voltage grades are optional.

Technical Data of 3V1 Series Pneumatic Solenoid Valves:

Model 3V1-M5 3V1-06 3V1-08
Medium Air (to be filtered by 40 μ m filter element)
Action Direct Acting
Way & Position 3 Port 2 Position
Port Size M5 1/8'' 1/4''
Orifice Size 1.0mm
Pressure Range 0 to 0.8MPa
Max. Resistance Pressure 1.2 MPa
Coil Voltage 12VDC, 24VDC, 110VAC, 220VAC
Coil Power AC: 5.5VA, DC: 4.8W
Max. Frequency 10 cycle/sec


Dimension of 3V1-06 Pneumatic Solenoid Valve:

3V1-06 Airtac Type Pneumatic Solenoid Valve 3 Way 2 Position 24VDC

Production Video of Pneumatic Solenoid Valves:

More Pneumatic Products for you to choose:

3V1-06 Airtac Type Pneumatic Solenoid Valve 3 Way 2 Position 24VDC3V1-06 Airtac Type Pneumatic Solenoid Valve 3 Way 2 Position 24VDC3V1-06 Airtac Type Pneumatic Solenoid Valve 3 Way 2 Position 24VDC

2/2 Way 3/2 Way 5/2 Way, Single Solenoid

3V1-06 Airtac Type Pneumatic Solenoid Valve 3 Way 2 Position 24VDC3V1-06 Airtac Type Pneumatic Solenoid Valve 3 Way 2 Position 24VDC3V1-06 Airtac Type Pneumatic Solenoid Valve 3 Way 2 Position 24VDC

5/2 Way, Double Solenoid 5/3 Way, Double Solenoid Pneumatic Hose Fittings

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
